OTR1100a UHF Desktop Reader
OTR1100a UHF RFID desktop reader is the ideal reader for UHF application development and card issuing applications. OTR1100a is a versatile reader that supports both EPC Class 1 Gen 2 and ISO 18000-6B standards. Comes with a built in compact antenna, OTR1100a’s firmware is fully compatible with OTR500 and OTR-2k reader range – making it a very scalable platform for UHF application development and prototyping.
| Operating Frequency | 868MHz to 963MHz |
| RF protocol | ISO18000-6B EPC Class 1 EPC Class 1 GEN 2 |
| Transmission Method |
FHSS or Fixed Frequency (Software Configured) |
| Antenna | Built-In |
| Maximum RF Power | 30 dBm |
| RF Power Resolution | <0.5 db |
| RF Power Range | 20 to 30 dBm (Software Configured) |
| Tag Identification Mode | Time Triggered or Event Triggered |
| Tag Identification Time | <8ms per tag |
| Tag Reading | Time: 5ms every 8 bytes Range: <20cm |
| Tag Writing |
Time: 25ms every 4 bytes Range: <10cm |
| Communication Interface | RS232 Wiegand26/34 |
| Power Supply |
5VDC |
| Power Consumption |
< 5W |
| Dimension | Reader: 98 x 60 x 22mm Packaging: 232 x 118 x 63mm |
| Weight |
0.65kg (Gross) 0.08kg (Net) |
| Temperature |
Operating: -20°C to +70°C Storage: -40°C to +85°C |
| Reader Indicators | Buzzer LED |
| Software Developer Kit | OTR-2k SDK (WinXP / Win7) |
*Subject To Change Without Prior Notice
