NXP Pegoda 710 NFC Reader

NXP’s Pegoda 710 NFC Reader

The Pegoda reader, CL RD701, is a contactless reader based on the CL RC632 reader IC. The CL RC632 is member of a family for highly integrated reader ICs for contactless communication at 13.56 MHz.

All layers of ISO14443A+B, ISO 15693 as well as the MIFARE ® classic crypto are supported.

The Pegoda reader is designed to fulfil several requirements.

It covers all functionality of the CL RC632 to be able to use this reader as a reference design for a new hardware design based on the CL RC632 reader IC and is designed for easy PC adaptation and application development as well.

ISO Standard ISO 14443A+B or ISO 15693
Operating Frequency 13.56MHz
Operating Distance 70 to 100mm
Compliant CE / FCC
Interface USB
Baud Rate 424 kbit
Power Supply 5 VDC
Operating Current 70mA to 250mA
Operating Temperature -10°C to +70°C
Dimensions 114 x 114 x 41mm
Weight 700g
Accessories Includes CL RD701 Pegoda reader
USB cable
Support System Windows 98 OSR2
Windows ME
Windows 2000
Windows XP
Software Developer Kit Pagoda Reader SDK.rar

*Subject To Change Without Prior Notice
