DS1982

DS1982

1Kb Add-Only iButton®
Datasheet : DS1982.pdf
SPECIAL FEATURES

  • 1024 bits Electrically Programmable Read-Only Memory (EPROM) communicates with the economy of one signal plus ground
  • EPROM partitioned into four 256-bit pages for randomly accessing packetized data
  • Each memory page can be permanently writeprotected to prevent tampering
  • Device is an “add only” memory where additional data can be programmed into EPROM without disturbing existing data
  • Architecture allows software to patch data by superseding an old page in favor of a newly programmed page
  • Reduces control, address, data, power, and programming signals to a single data pin
  • 8-bit family code specifies DS1982 communications requirements to reader
  • Reads over a wide voltage range of 2.8V to 6.0V from -40°C to +85°C; programs at 11.5V to 12.0V from -40°C to +50°C
