AT24CM01

AT24C01/02/04/08/16 | AT24C32SC/64SC | AT24C128SC/256SC | AT24C512C | AT24C1024SC| AT24CM01
AT24CM01

Two-wire Serial EEPROM
1M (131,072 x 8)
Datasheet : AT24CM01.pdf
Features

  • ow-Voltage and Standard Voltage Operation:
    • VCC = 1.7V to 5.5V
    • VCC = 2.5V to 5.5V
  • Internally Organized as 131,072 x 8 ( 1M )
  • Industrial Temperature Range: -40°C to +85°C
  • I2C-Compatible (Two-Wire) Serial Interface:
    • 100 kHz Standard mode, 1.7V to 5.5V
    • 400 kHz Fast mode, 1.7V to 5.5V
    • 1 MHz Fast Mode Plus (FM+), 2.5V to 5.5V
  • Schmitt Triggers, Filtered Inputs for Noise Suppression
  • Bidirectional Data Transfer Protocol
  • Write-Protect Pin for Full Array Hardware Data Protection
  • Ultra Low Active Current (3 mA maximum) and Standby Current (6 μA maximum)
  • 256-byte Page Write Mode:
    • Byte write and partial page writes allowed
  • Random and Sequential Read Modes
  • Self-timed Write Cycle:
    • All Write operations complete within 5 ms maximum
  • Built in Error Detection and Correction
  • High Reliability：
    • Endurance: 1,000,000 write cycles
    • Data Retention: 100 Years
  • Green Package Options (Lead-free/Halide-free/RoHS compliant)
  • Die Sale Options: Wafer Form and Bumped Wafers
