AT24C512C

Two-wire Serial
EEPROM Smart Card Module
512K (65,536 x 8)
Datasheet : AT24C512C.pdf
Features

• Low-voltage and Standard-voltage Operation:
  • VCC = 1.7V to 3.6V
  • VCC = 2.5V to 5.5V
• Internally Organized 65,536 x 8
• Industrial Temperature Range: -40°C to +85°C
• Two-Wire Serial Interface:
  • 100 kHz Standard mode, 1.7V to 5.5V
  • 400 kHz Fast mode, 1.7V to 5.5V
  • 1 MHz Fast Mode Plus (FM+), 2.5V to 5.5V
• Schmitt Triggers, Filtered Inputs for Noise Suppression
• Bidirectional Data Transfer Protocol
• Write-Protect Pin for Full Array Hardware Data Protection
• Ultra Low Active Current (3 mA maximum) and Standby Current (6 μA maximum)
• 128-byte Page Write Mode (Partial Page Writes Allowed)
• Random and Sequential Read Modes
• Self-timed Write Cycle within 5 ms Maximum
• ESD Protection > 4,000V
• High Reliability:
  • Endurance: 1,000,000 Write Cycles
  • Data Retention: 100 Years
• Green Package Options (Lead-free/Halide-free/RoHS compliant)
• Die Sale Options: Wafer Form and Tape and Reel Available
