AT24C01A/02/04/08/16SC

AT24C01/02/04/08/16 | AT24C32SC/64SC | AT24C128SC/256SC | AT24C512C | AT24C1024SC| AT24CM01
AT 2 4 C 0 1 A S C AT 2 4 C 0 2 S C AT 2 4 C 0 4 S C AT 2 4 C 0 8 S C AT 2 4 C 1 6 S C

AT24C01AS C / AT24C02SC / AT24C04SC
AT24C08SC / AT24C16SC

2-wire Serial EEPROM Smart Card Modules
1K (128 x 8)
2K (256 x 8)
4K (512 x 8)
8K (1024 x 8)
16K (2048 x 8)
Datasheet : AT24C01A_02_04_08_16SC.pdf
Features

  • Low-voltage and Standard-voltage Operation, VCC = 2.7V to 5.5V
  • Internally Organized 128 x 8 (1K), 256 x 8 (2K), 512 x 8 (4K), 1024 x 8 (8K) or 2048 x 8 (16K)
  • Two-wire Serial Interface
  • Schmitt Trigger, Filtered Inputs for Noise Suppression
  • Bidirectional Data Transfer Protocol
  • 400 kHz Compatibility
  • 8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes
  • Partial Page Writes Allowed
  • Self-timed Write Cycle (5 ms max)
  • High-reliability
    • Endurance: One Million Write Cycles
    • Data Retention: 100 Years
    • ESD Protection: >3000V
