AT45D011
AT45D011

1-megabit
5.0-volt Only
Serial
DataFlash®
Datasheet : AT45D011.pdf
Features

  • Single 4.5V – 5.5V Supply
  • Serial Interface Architecture
  • Page Program Operation
    • Single Cycle Reprogram (Erase and Program)
    • 512 Pages (264 Bytes/Page) Main Memory
  • Optional Page and Block Erase Operations
  • One 264-byte SRAM Data Buffer
  • Internal Program and Control Timer
  • Fast Page Program Time – 7 ms Typical
  • 120 µs Typical Page to Buffer Transfer Time
  • Low Power Dissipation
    • 15 mA Active Read Current Typical
    • 10 µA CMOS Standby Current Typical
  • 15 MHz Max Clock Frequency
  • Hardware Data Protection Feature
  • Serial Peripheral Interface (SPI) Compatible – Modes 0 and 3
  • CMOS and TTL Compatible Inputs and Outputs
  • Commercial and Industrial Temperature Ranges
